Air Manifolds provides many connection options for isolation . From One Inlet you can create upto 24 outlets .

FAV Air Header are available in a wide array of configurations based on end users requirement such as NPT, BSP, Butt Weld, Flanged, Socket Weld or Compression outlets. Air Headers is a substitute for multiple valve assemblies, which normally operates from one originating point. The Air Manifolds are configured for accommodating various outlet valves. The inlet-connection can have variety of end connection.

Standard Air Header Format

Number of Ports/Outlets :4 Way to 24 Way
Pipe Size :  1" to 4"
Pipe Schedule : Sch 10,Sch 40,Sch 80.Sch 160
Inlet : Flanged ,Ball Valve, Needle Valve, NPT Female or Male
Outlets:  Ball Valve, Needle Valve, NPT Female or Male,Socket Weld ,Butt Weld
Drain :Flanged ,Ball Valve, Needle Valve, NPT Female or Male,Plugs

Air Manifolds with Ball Valves
Air Header with Ball Valve
Air Distribution Manifold with Needle Valve
Air Header with Needle Valve

Some common sizes of Air Headers, Air Distribution Manifolds are

FAV SS 316

Air Header 10 way (5x5)

Inlet 2" NPTF Ball Valve

Outlet 1/2" NPTF Ball Valve with 1/2" NPTM Plug

Drain 1/2" NPTF Ball Valve with 1/2" NPTM Plug



FAV SS 304 Air header, 12 Way

Pipe Size 1"

Inlet 1/2" NPT Female

Outlet 12 off SS 304 Ball Valve 1/4" NPT F

Drain SS 304 Needle Valve 1/2" NPT F



FAV SS 304 Air header, 16 Way

Pipe Size 1"

Inlet 1/2" NPT Female

Outlet 16 off SS 304 Ball Valve 1/4" NPT F

Drain SS 304 Needle Valve 1/2" NPT F
