Hex Reducing Bushing,10000 psi
Hex Reducing Bushing,10000 psi

Hex Reducing Bushing,10000 psi

FAV is the manufacturer of High Pressure Hex Reducing Bushing,10000 psi, 700 Bars. It has NPT Male Connection on one side and NPT Female Connection on the other side  .

Standard Material for Hex Reducing Bushing ,10000 psi is SS 316 but is also available in Carbon Steel, Brass, Hastelloy , Inconel alloys , Monel alloys , Titanium , Super Duplex & Duplex .

Common sizes are 1/4" NPT Male X 1/2" NPT Female, 3/8" NPT Male X 1/4" NPT Female, 1/2" NPT Male X 3/8" NPT Female , 3/4" NPT Male X 1/2" NPT Female, 1" NPT Male X 3/4" NPT Female.

High Pressure Fittings are used in almost all industrial applications where threaded connections are involved . It also used in Hydro testing setup .



PART No. P1 P L 0D F
 NPTM  NPTF  HEX
FHPF/10K/RB/21-1I 1/8 1/16 26.2 4.8 7/16
FHPF/10K/RB/4I-2I 1/4 1/8 26.9 7.1 9/16
FHPF/10K/RB/6I-2I 3/8 1/8 21.8 8.6 11/16
FHPF/10K/RB/6I-4I 3/8 1/4 30.2 9.5 3/4
FHPF/10K/RB/8I-4I 1/2 1/4 27.4 11.4 7/8
FHPF/10K/RB/8I-6I 1/2 3/8 35.8 11.9 7/8
FHPF/10K/RB/12I-4I 3/4 1/4 27.4 11.4 1-1/16
FHPF/10K/RB/12I-6I 3/4 3/8 27.4 15.0 1-1/16
FHPF/10K/RB/12I-8I 3/4 1/2 41.4 15.7 1-1/16
FHPF/10K/RB/16I-4I 1 1/4 34.8 11.4 1-3/8
FHPF/10K/RB/16I-6I 1 3/8 34.8 15.0 1-3/8
FHPF/10K/RB/16I-8I 1 1/2 34.8 18.5 1-3/8
FHPF/10K/RB/161-12I 1 3/4 47.0 22.4 1-3/8
Hex Bushing
Hex Bushing
High Pressure Hex Bushing
