Low Pressure LP Male to Male JIC Adapter 10000 psi
Low Pressure LP Male to Male JIC Adapter 10000 psi

Adapter Low Pressure LP Male to Male JIC 10000 psi

Ordering Number Px-Connection Type Dimension, in. (mm) Working Pressure psig (bar)
L F E
FAV/AF/LP/JIC1 1/4 JIC 1.37 (34.9) 0.50 (12.7) 0.09 (2.4) 15000 (1034)
FAV/AF/LP/JIC2 3/8 JIC 1.44 (36.5) 0.63 (15.9) 0.09 (2.4) 15000 (1034)
FAV/AF/LP/JIC3 1/2 JIC 1.63 (41.3) 0.81 (20.6) 0.09 (2.4) 15000 (1034)
FAV/AF/LP/JIC4 5/8 JIC 1.75 (44.5) 0.94 (23.8) 0.09 (2.4) 15000 (1034)
FAV/AF/LP/JIC5 3/4 JIC 1.94 (49.2) 1.13 (28.6) 0.09 (2.4) 15000 (1034)
FAV/AF/LP/JIC6 1 JIC 2.06 (52.4) 1.37 (34.9) 0.09 (2.4) 15000 (1034)
FAV/AF/LP/JIC7 1/4 JIC 1.63 (41.3) 0.63 (15.9) 0.17 (4.4) 15000 (1034)
FAV/AF/LP/JIC8 3/8 JIC 1.63 (41.3) 0.63 (15.9) 0.19 (4.8) 15000 (1034)
FAV/AF/LP/JIC9 1/2 JIC 1.75 (44.5) 0.81 (20.6) 0.19 (4.8) 15000 (1034)
FAV/AF/LP/JIC10 5/8 JIC 1.94 (49.2) 0.94 (23.8) 0.19 (4.8) 15000 (1034)
FAV/AF/LP/JIC11 3/4 JIC 2.06 (52.4) 1.13 (28.6) 0.19 (4.8) 15000 (1034)
FAV/AF/LP/JIC12 1 JIC 2.25 (57.2) 1.37 (34.9) 0.19 (4.8) 15000 (1034)
FAV/AF/LP/JIC13 1/4 JIC 1.69 (42.9) 0.75 (19.1) 0.17 (4.4) 15000 (1034)
FAV/AF/LP/JIC14 3/8 JIC 1.69 (42.9) 0.75 (19.1) 0.23 (5.8) 15000 (1034)
FAV/AF/LP/JIC15 1/2 JIC 1.81 (46.0) 0.81 (20.6) 0.25 (6.4) 15000 (1034)
FAV/AF/LP/JIC16 5/8 JIC 1.94 (49.2) 0.94 (23.8) 0.25 (6.4) 15000 (1034)
FAV/AF/LP/JIC17 3/4 JIC 2.13 (54.0) 1.13 (28.6) 0.25 (6.4) 15000 (1034)
FAV/AF/LP/JIC18 1 JIC 2.25 (57.2) 1.37 (34.9) 0.25 (6.4) 15000 (1034)
FAV/AF/LP/JIC19 1/4 JIC 1.81 (46.0) 0.94 (23.8) 0.17 (4.4) 15000 (1034)
FAV/AF/LP/JIC20 3/8 JIC 1.81 (46.0) 0.94 (23.8) 0.23 (5.8) 15000 (1034)
FAV/AF/LP/JIC21 1/2 JIC 1.94 (49.2) 0.94 (23.8) 0.31 (8.0) 15000 (1034)
FAV/AF/LP/JIC22 5/8 JIC 2.00 (50.8) 0.94 (23.8) 0.37 (9.4) 15000 (1034)
FAV/AF/LP/JIC23 3/4 JIC 2.19 (55.6) 1.13 (28.6) 0.37 (9.5) 15000 (1034)
FAV/AF/LP/JIC24 1 JIC 2.31 (58.7) 1.37 (34.9) 0.37 (9.5) 15000 (1034)



Some Common Sizes for SS 316 Adapter LP Male X Male JIC are

  1. FAV SS 316 Adapter 1/8” LP Male x 1/8” JIC Male 15000 psi
  2. FAV SS 316 Adapter 1/4” LP Male x 1/4” JIC Male 15000 psi
  3. FAV SS 316 Adapter 3/8” LP Male x 3/8” JIC Male 15000 psi
  4. FAV SS 316 Adapter 1/2” LP Male x 1/2” JIC Male 15000 psi
  5. FAV SS 316 Adapter 3/4” LP Male x 3/4” JIC Male 15000 psi
  6. FAV SS 316 Adapter 1” LP Male x 1” JIC Male 15000 psi
